2021 Update

January 4th, 2021 § 0 comments § permalink

XinCheJian has moved from its old location at the end of December 2020, the new location from this point forward is:

HuiDe Mansion,
15/F (take the elevator to the 13th floor and walk up),
65 Huangjiaque Road,
Huangpu district,
Shanghai
China
200011

上海 上海市 黄浦区,
黄家阙路65号惠德大厦15楼
200011

Most of the updates for the last year have moved to WeChat, please follow XinCheJian on WeChat

自制新车间:荧光衣 | XinCheJian DIY: Fluorescent dance cloth

November 9th, 2016 § 0 comments § permalink

自制新车间 | XinCheJian DIY 自制新车间主要为大家提供出自于新车间会员的作品。通过该平台,大家一方面可以了解新车间会员的作品原理,自己DIY。另一方面,也可以用合理的价格购买相应的作品和套件。我们保证,该平台不是“淘宝”店,不接受所有商业作品,所有发布的作品均出自于新车间会员! dancee 项目来源 该项目来源于新车间会员。当时他还是高中生。在一次班级表演中,他突发奇想,决定做荧光衣增强舞台效果。之后不断改进,成功在大学迎新晚会上推出。如今,他愿意和大家分享该项目 套件: 衣服,裤子,电池,Arduino主控板,热熔枪,EL冷光线5m x 2条,2m x 1条(颜色可选),一套驱动器和电线若干,12V电池盒 x 3(如果不想在驱动器上做修改,可以选择用驱动器自带的8节1.5V干电池的电池盒作为电源则不需要使用这个。但重量大大增加。),继电器 x 1 dance2 制作方法: 首先当然是将EL冷光线用热熔胶粘到衣服上,先前设计好图案,图案最好能展现出关节、肌肉的轮廓,这样舞蹈会显得美观。多条不同颜色的EL冷光线的切换可以实现变色 dance3 然后是将继电器接入到EL冷光线的电路中。一并做在衣服上。继电器的使用方法:http://wiki.dfrobot.com.cn/index.php/(SKU:DFR0017) 衣服做好以后就是对芯片进行编程,让灯光随着音乐的时间闪烁。可以实现人在高空中消失,从空中落下,原地翻转,千手观音,等普通的舞蹈中展现不出的效果。 如图,一个继电器控制着一段灯光,比如继电器1控制的是紫色的灯光,继电器2控制 的是一段蓝色的灯光,继电器三控制的是另外一段蓝色的灯光。这样便可以实现变色,变身 等效果。   以上是一个简单的例子。当然在时间的编写过程中最好能在每一个延时后面标记上这是第几秒,方便之后的修改。第一次写的时候没有经验,都没有留下记号,要修改的时候就十分麻烦,还容易出错,最后不得不重新从头到尾写了一次。 写完时间就是要修改。比如当跳舞的同学跳到半空中时要灭灯,可能一开始灯灭早了或灭晚了,就是要通过不断地修改才能达到很好的效果。 如果只有一个继电器就只需要一个输出端。 价格: 550元/套成品 500元/全套件,包含衣服,裤子,电池,Arduino主控板,热熔枪,EL冷光线5m*2条,2m*1条(颜色可选),一套驱动器和电线若干,12V电池盒*3(如果不想在驱动器上做修改,可以选择用驱动器自带的8节1.5V干电池的电池盒作为电源则不需要使用这个。但重量大大增加。),继电器*1。 410元/半套件,包含电池,Arduino主控板,热熔枪,EL冷光线5m*2条,2m*1条(颜色可选),一套驱动器和电线若干,12V电池盒*3(赠送,如果不想在驱动器上做修改,可以选择用驱动器自带的8节1.5V干电池的电池盒作为电源则不需要使用这个。但重量大大增加。),继电器*1。衣服,裤子自备 danceqr]]>

Arduino入门之自动浇花系统搭建 11月20日

November 9th, 2016 § 0 comments § permalink

Huodongxing: 上海静安愚园东路28号3号楼一楼 新车间 课程介绍 随着人们生活节奏的加快,即使是最爱的花草浇水也无暇顾及,偶而出差、旅行、探亲也是很正常的事情,而家中花草谁来管理? 花草生长问题80%以上是由花儿浇灌问题引起;好不容易种植几个月的花草,因为浇水不即时,长势不好,用来美化家园的花草几乎成了“鸡肋”;因此我们为广大DIY爱好者,开发了一款可以自己编程,设置参数,自己动手组装的基于Arduino的自动浇花控制器,使用土壤湿度传感器对土壤湿度进行监测,通过温湿度传感器对室内温度、湿度进行测量,控制水泵或电池阀进行浇水,从而达到自动浇灌的目的。 此课程是基于Arduino的自动浇花套件,用户可以自己编程实现更多的功能,例如智能家居,物联网等。相关文档中提供全面的套件组装教程和调试软件,您完全不用担心安装的问题。

二、自动浇花系统技术规格及套件清单

技术规格: ·      输入电源:6-12V ·      支持湿度传感器和碳棒检测土壤湿度 ·      支持潜水泵和双稳态电磁阀浇水 ·      具有室内温度和湿度检测 ·      具有土壤湿度阀值调节 ·      具有4个模拟口,5个数字口 ·      支持xbee无线数传 ·      支持USB接口下载程序 ·      具有DC2.1和接线柱电源接口 ·      潜水泵额定电压:3.5-12V ·      潜水泵最大扬程:200cm ·      模块尺寸:70 x 60mm ·      支持防水型DS18B20温度传感器 清单: ·      Free Life自动浇花系统控制器          1个 ·      Micro USB线                                      1根 ·      DHT11温湿度传感器                            1个 ·      土壤湿度传感器                                     1个 ·      模拟接口转数字接口传感器连接线     2根 ·      潜水泵 1个(注意:潜水泵必须在水中使用,不能露出水面!) ·      潜水泵电源连接线                                 1根 ·      主板电源连接线                                    1根 ·      橡胶水管                                                1米 ·      塑料外壳                                                1个 ·      2mm一字螺丝刀                                   1个 ·      1号十字螺丝刀                                      1个 ·      电子文档上位机软件                            1份

课程内容安排

预计课程持续2~3小时 1、什么是Arduino以及arduino智能硬件平台应用 2、电路基础和简单编程知识介绍 3、自动浇花系统电子元器件介绍,包括控制模块,传感器等。 4、指导学生动手搭建 5、搭建完后指导调试以及参数设置与修改 6、点评与总结 要求: 8岁以上,小朋友最好有家长陪同。 笔记本电脑,预安装Arduino(https://www.arduino.cc/en/Main/Software  )和Eagle( http://www.cadsoftusa.com/download-eagle/freeware/) 时间: 11月20日,14:00 – 17:00 价格: 新车间会员:300/人,新车间非会员:350/人 套件:300/人 报名请扫描二维码,或点击阅读原文。更多问题发送邮件至[email protected]]]>

学习使用MATLAB 11月13日 | Learn how to use MATLAB November 13

November 9th, 2016 § 0 comments § permalink

Huodongxing: 上海静安愚园东路28号3号楼一楼 新车间 时间: 14:00 - 16:00,周日,11月13日   简介: Biggerlab成立于2015年,致力于为中国培养具有STEM素养的人才,必果科技拥有包括Arduino硬件开发,IOS编程,数据可视化,VR虚拟现实等一整套完整科技教育课程和一流的导师资源,从零开始培养中国学生的科技理工素养,以求在未来和全世界学生的竞争中脱颖而出,我们的愿景是培养10%的中国学生,改变未来90%中国人的生存状态。   工作坊介绍: 在这个工作坊将会用一种有趣的方式来教你入门MATLAB这款应用广泛,性能强大的软件!—–用MATLAB生成的函数模拟各种乐器的声音! 工作坊内容包括 -入门并熟悉MATLAB基本功能 -学习MATLAB绘制多种函数图象 -用余弦波来模拟乐器的声音 -用MATLAB来消除/添加录音中回声   MATLAB MATLAB(矩阵实验室)是MATrix LABoratory的缩写,是一款由美国The MathWorks公司出品的商业数学软件。MATLAB是一种用于算法开发、数据可视化、数据分析以及数值计算的高级技术计算语言和交互式环境。除了矩阵运算、绘制函数/数据图像等常用功能外,MATLAB还可以用来创建用户界面及与调用其它语言(包括C,C++,Java,Python和FORTRAN)编写的程序。   本工作坊为全英语授课 Biggerlab会提供MATLAB软件,参加者需要自备笔记本电脑。本次指导老师是NYU电子工程与自然科学大四学生,有丰富的硬件开发与软件工程经验,曾参与过用加速度传感器识别人体姿势的项目。她的毕业论文研究方向是如何智能化的将绿色节能科技带进校园 费用: 新车间会员:260/人,新车间非会员:300/人。有问题,请发送邮件至[email protected]. 参加工作坊请携带笔记本电脑]]>

Unity3D入门 11月12日 | Intro to Unity 3D November 12th

November 9th, 2016 § 0 comments § permalink

Huodongxing: 上海静安愚园东路28号3号楼一楼 新车间 Alan是frog design的高级顾问。通常他给公司的软件工程和科技策略提供咨询,周末他则将时间花在Unity游戏编程,原型设计以及交互式艺术上。他的游戏编程生涯已经有20年了 What can Unity do? Unity is used to develop video games for PC, consoles, mobile devices and websites. Unity3D是由Unity Technologies开发的一个让玩家轻松创建诸如三维视频游戏、建筑可视化、实时三维动画等类型互动内容的多平台的综合型游戏开发工具,是一个全面整合的专业游戏引擎。Unity类似于Director,Blender game engine, Virtools 或 Torque Game Builder等利用交互的图型化开发环境为首要方式的软件。其编辑器运行在Windows 和Mac OS X下,可发布游戏至Windows、Mac、Wii、iPhone、WebGL(需要HTML5)、Windows phone 8和Android平台。也可以利用Unity web player插件发布网页游戏,支持Mac和Windows的网页浏览。它的网页播放器也被Mac widgets所支持。很多游戏设计师,用Unity3D来设计VR游戏。 Workshop Description 在课程的2.5个小时内,我们从零基础开始,学习用Unity编写基于物理原理的简单的游戏。 Workshop structure 工作坊结构 1. Introduction 入门介绍 2. What is Unity and how it compares to other game engines Unity是什么和其他游戏引擎有什么不同 3. Unity fundamental concepts – Scenes and GameObjects Unity的基本原理 – 场景和游戏物件 4. Game Physics 游戏物理 5. Your first script 编写脚本 6. Managing Game State 管理游戏场景 7. An overview of more advance Unity concepts (animation, lighting, particles) 其他更先进的Unity知识(动画,光,插件) This workshop can help you 工作坊能做什么 –  知道怎么用Unity – 知道怎么写简单的游戏 – 知识在你的游戏编程生涯中的下一步怎么走 In order to attend you should 工作坊准备: – 至少知道loop(循环)是什么 – 带上笔记本电脑,并将电脑预装unity –  Unity下载地址: https://store.unity.com/download?ref=personal The class will be taught in English only. 课程将以全英文进行。 Time 时间: 11月12日,周六,14:00 – 16:30 Location 地点: XinCheJian, East Yuyuan Rd, Number 28, Building 3 (Near to Tongren Rd) / 愚园东路28号3号楼1层 新车间 Fee 费用:   新车间会员:300/人 新车间非会员:350/人 非会员套餐价:400元/人,课程加一个月会员费。]]>

Project Spotlight: Hover Pen/Hover Train

November 8th, 2016 § 0 comments § permalink

Ivan suspends 100g with YCBO levitation[/caption] For the past two months, Sean Purser-Haskell and Ivan Tchekashkin have been developing practical demos to showcase superconductor technology. Using YBCO (Yttrium Barium Copper Oxide) cooled by liquid nitrogen to -196 degrees Celsius, they’re able to levitate magnetic materials. They’ve applied this special property to create what they call the “Hover Pen” – a white-board with a marker that writes on its own; and the “Hover Train” – a scale model transit system that suspends superconductor-enabled train cars with a magnetic rail. [caption id="attachment_8078" align="alignnone" width="454"]hoverpenteam From left to right: Maciej Dudek, Danny Kuo, Ivan Tchekashkin, Sean Purser-Haskell[/caption] At last Wednesday’s open house the team demonstrated the “Hover Pen” to a mesmerized crowd. hoverpenytscreenshot Although it’s easy to use YBCO to levitate small magnets in place – a simple physics demonstration – scaling this property is another story. You quickly encounter problems when asked to achieve a certain level of control, or to “levitate heavy things.” The duo have had to rely on more than just past education and work experience; they’ve had to consider plenty of electromagnetic theory and have frequently risked their fingers playing with magnets and liquid nitrogen. Although they’ve focused most of their time on issues with superconductor technology, they recognize that putting together the whole system required a large base of knowledge – most gained from past projects at Xinchejian. And without the contributions of Maciej Dudek and Danny Kuo, the demos wouldn’t have their clean form or peripheral functions. Their demos were showcased by a superconductor manufacturer at the China International Industry Fair this past week. Stop by Xinchejian and take a look at the (almost) finished products!]]>

智能机械臂制造工作坊 11月5日 | Robot Arm Workshop November 5th

October 25th, 2016 § 0 comments § permalink

智能机械臂制造工作坊介绍: 想动手制作一台神奇的机械臂吗?它能够画画、递东西、和您做游戏,快来看看“创客梦工厂”中的神奇工具“机械臂制作和编程”工具组吧,掌握了这套工具就能够制作出个性化的机械臂了,是不是很有趣呢! 培训课时安排及内容介绍: 第一课:机械臂安装和讲解 第二课:控制软件的安装和讲解 此次工作坊能帮助您: 1. 快速的制作一台机械臂 2. 体验梦想变成现实的成就感 3. 体验艺术创作的快乐 4. 增加想象力和创造力 5. 学会编程与控制 6. 通过创造来解决生活中遇到的实际问题 值得期待的: 本次工作坊的目标是帮助热爱机械的您制作一台属于自己的机械臂,通过编程和控制让它完成一些日常的工作,让我们像魔术师一样快乐的创造吧! 谁应该注册: 热爱电子和机械的您、活泼可爱对世界充满好奇的小朋友、对创客文化感兴趣的爱好者、想自己DIY一件智能产品送给亲人朋友的小伙伴,以及各个年龄段充满奇思妙想的朋友都适合参加本次工作坊,并且在动手创造的过程中将收获意想不到的喜悦和感动。 往期成果展示: screen-shot-2016-10-25-at-10-43-14-am 主讲人的联系方式: 如果有任何疑问可以选择以下几种方式与我取得联系 微信:archarry QQ:514248050 邮箱:[email protected] 电话:15601786625 教学规模: 5-10人/期 时间: 2016年11月5日,6日 10:00 – 16:00 课程费用(包含一套机械臂材料): 早鸟价格: 两堂课,980/人(仅限5人,会员优先) 正常价格: 会员:两堂课,1100/人 非会员:两堂课,1200/人 报名请发送邮件至[email protected]。]]>

DIY GPS Assisted Foldable Drone Oct 22 | 自制带GPS的可折叠式四轴飞行器 10月22日

October 18th, 2016 § 0 comments § permalink

上海静安愚园东路28号3号楼一楼 新车间 diygps_oct22_16 About the instructor/老师简介 : I am Andrew, been in Xinchejian for a couple years now, currently a college student and an entrepreneur. Over the years my experience with electronics have left a couple proud creations, such as laser gun, DIY drone, tesla coils, and etc.  A year ago I successfully crowd funded design project Eggie, “The worlds most advanced night light” this has given me ample of experiences in research and design,prototyping, manufacturing, marketing and etc. All of which you are very welcome to ask me. 大家好,我是Andrew。在新车间有几年了,我现在是大学生/创业家。之前的电子背景让我做出很多有意思的东西,我最近在kickstarter上成功的众筹了一个设计产品。所以关于研发,销售,生产都有很多经验。 Workshop description/工作坊介绍: Most DIY drones suffer the lack of function, looks, and usability.   Rendering them to be always considered atoy. This GPS assisted foldable drone allows, the builder to fully experience the joy of flight, with its GPS position hold feature it can stay in air even if you don’t touch the controller.  Its aesthetically designed body is made out of carbon fiber composites for light weight and durability. The smart foldable frame of allows the user to take it where ever they want.   If you are interested, please join the workshop and experience the joy of creating your own flying drone! 大多数DIY无人机经常受限于其功能性、美观,及可用性使得这些产品总是被看作是一个玩具。GPS定位系统和可折叠机架可以让创客充分体验飞行的乐趣,不用再担心偏移方向或者失控的可能,并且随着GPS定位系统的功能性加入可以使得无人机在空中的悬停可以完全脱离遥控器。机体外部碳纤维材料使得无人机更具美观性,更轻,更坚固及耐用。可折叠机身设计使得创客在携带无人机时更方便。 diygps2_oct22_16 Workshop structure: Hour 0: Explainingthe basic principles of the drone, such as its electronic systems, brief thephysics behind how it files. Introduce the parts provided by me, and explain what each component does. 解释基本的无人机规则,电子系统以及电子元器件。 Hour 1: Start ofthe assembly 开始组装 Hour2: Changing the settings and preparing drone for flight 调试无人机 Hour 3: Testflight, and further adjusting 试飞和调试   Requirement: Over the age of 15, or accompanied by a parent. Bring computer, must bewindows operating system 要带电脑和热情, 低于15岁需要家人陪同. 带电脑。   Price: Members and first 5 non-member: 3799 rmbfor the complete drone kit and lesson plan Non-member: 3999rmbfor the complete drone kit and lesson plan 会员和前五名非会员:全套套件和课程3799 人民币 非会员: 全套套件和课程 3999 人民币   Time/时间: 10/22/2016 9:00am   Disclaimer/免责声明: I am notresponsible for any illegal or misuse of the drone. Please follow allregulation and rules of drones in China. I am also not responsible for anyinjuries that results from the drone, I will however discuss the dangers andwhat to be aware of while starting and flying. This is not a toy! 此工作坊,首先要求在严格的使用方法和组装等必要的模型技术的前提条件下,对出现的任何问题,我们只负责飞机本身,除此之外所造成的其它任何损失和伤害不负责. Sign up: Send Email to [email protected] to tell her that you wanna make your own fabulous foldable drone! 报名请发送邮件到[email protected].]]>

Project Spotlight: Monuments for Progress

October 15th, 2016 § 0 comments § permalink

Over a period of six months, architect/researcher Cédric Van Parys travelled to all the different corners of Shanghai, seeking the architectural landmarks that gloriously represent Shanghai’s breakneck progress since the early 1990’s. These urban centerpieces were located on top of the skyscrapers at the gravitational centerpoints of Shanghai’s rapidly expanding and merging districts. Climbing to the top of the numerous surrounding skyscrapers, he recorded (photographed and filmed) the crowns of each of these architectural landmarks. Working from Xinchejian, he has reproduced the landmarks into a series of associated prototypes. These 3D-printed physical scale models represent a radically different aesthetic perspective on Shanghai’s progress of the last decades. A first selection of the Monuments for Progress will be on show as part of the exhibition: Grain God’s Narrative at the Swatch Art Peace Hotel on the Bund – one of the city pavilions of the Shanghai Art Biennale. For more information, please visit: http://monumentsforprogress.altervista.org]]>

Kin interview

August 30th, 2016 § 0 comments § permalink

对不起,此内容只适用于美式英文
