感谢上海科技报的邀请，9／17日新车间参加了在复兴公园的上海科普日活动。

]]>

Another exciting afternoon racing robots with friends. 😉

Taken by @vnsavitri

Taken by Ricky

]]>

XinCheJian crashed party at Barcamp Shanghai! We took over a room!

Paul and his very emotional plant

Susan presented urban farming.
– Posted using BlogPress from my iPhone

More from Weibo

@叶露洁lulu：barcamp中的urban farming. 有意思夯.可以自给自足无污染哈

@传说中的死胖子：#Barcamp# @新车间

@新媒体花园：XinCheJian @ Shanghai Barcamp, 源址http://t.cn/agj6JU 花园址http://t.cn/aYoNw3

@TopGeek：barcamp 几个玩开源硬件的哥在外面放一个遥控飞船

@联合创业办公社：#barcamp# meeting rm2 正在展示四轴飞机

@Henry谷歌：Ricky在barcamp上介绍hackerspace有关100 year starship的有趣项目

@老外废话：新车间今天在上海Barcamp有很多演示 @新车间 @rngadam @nihaopaul @李大维

]]>

==== Hacking Wednesdays ==== If you want to try your robot in this weekends race and have yet to finish it or build one, dont fear, come down to XinCheJian tonight and buy a R/C car like rickys 70rmb, rip the guts out and replace it with an Arduino 180rmb, theNelsons h-bridge shield 50rmb and 2 ultra sonic sensors 35rmb.. everything you need is in the space, not only will you be a hacker but you’ll learn some awesome skills while you do it. Tonight Min Lin and Ricky will be around to share stories from their recent hacking journeys. Get an insight into processing. we have a special guest coming down who’ll be setting up a processing workshop, find out whats involved tonight. Michael (RubberDucky) will be drilling into the walls to setup some computer benches, and also hooking up his mega-super-awesome-button-box for the new restricted toys (lathes, mills, bandsaw, drill) Paul will be discussing the lock-picking study with interested participants. Lio will be figuring out how he’s going to do the bamboo go-kart with those interested for the ben heck challenge (find out more tonight) and how you can be involved. After the event around 9pm the hackers will take to the tracks for some go-karting “research” at Chang Feng park indoor race track for some super awesome driving skills “bring a head mounted camera” If you thought this Wednesday is fun, wait for the weekend..

==== This Weekend ====

Saturday – all day: Organic waste workshop.. find out how to make bio-diesel, sign up and more information here: http://xinchejian.com/event/?regevent_action=register&event_id=55&name_of_event=OrganicWasteRecyclingWorkshop Saturday afternoon – 5 presentations from XinCheJian will be delivered at _Barcamp_ Shanghai so come and show your support for xinchejian.. sign up and more information here: http://techyizu.org/shanghai-barcamp-2011-september-24 Sunday morning – Ardublock workshop.. never programmed in arduino before? use ardublock to visually program. sign up here: http://xinchejian.com/event/?regevent_action=register&event_id=58&name_of_event=ArduBlockWorkshop Sunday afternoon – Robo Racing championship, find out if the Title stays with XinCheJian for a 3rd victory, find out if anyone can take on theNelsons or mindstorm robots! Man vs Machine will Machine win again! Sign up here: http://xinchejian.com/event/?regevent_action=register&event_id=57&name_of_event=RoboracingCompetition ]]>

理解和掌握数字逻辑是能成为一个更好的创客的关键部分。为实现这个关键部分，而获得更好的技能，周日9月18日在新车间举行了我们的第一个FPGA研讨会。这次研讨会是由Steven Wang和Kiki Yao两位Digilent 公司的工程师来作讲解，他们首先演示了一些不同FPGA的运用，比如720p的实时视频硬件编码和用FPGA作为任天堂来执行超级马里奥游戏。 演示完毕後，他们教导了如何使用的Xilinx ISE WebPACK 的FPGA 设计软件来创建和测试几个简单的VHDL设计。 Digilent公司也慷慨捐赠了一个Nexys3赛灵思FPGA开发板给新车间，让任何有兴趣的会员来学习使用。 我们使用7400集成电路及FPGA数字逻辑初步的学习Wiki页面. 欢迎大家一起纪录学习！ ]]>

Lio testing the master switch made by Michael for the mechanical tools.  Safety first!

]]>

雾气箱的效果非常的好，几天的时间，移植的植物就开始长出很漂亮的根。

– Posted using BlogPress from my iPhone
]]>

刚安装了超声波雾化器的气耕箱

]]>

细细想来，为了仍这个东西上天已经折腾了一年的时间了，试了无数的方案，也受到了无数人的帮助。终于是上天了，下面就是整机的照片。样子有点丑，各位hold住。

这个飞行器是以上天为目标，所以机架什么都是最低成本制作。用两块钱买来的PVC管子加上一个捡来的饮用水桶就成了四轴的机架。

用了两块电池，kk飞控，四个新西达1000kv电机，四个新西达30A电调。下面是控制部分的特写。

下面是第一次飞行视频。

http://v.youku.com/v_show/id_XMzA0NDI3MjYw.html

]]>
