遥控小车的改造 May 3rd, 2011

今天完成了遥控车的改造，这是自主控制的第一步。这辆车是在淘宝上买的，结构很简单，控制很简陋。方向就是将电机打死，这时候电流会非常大，而且对于将来的自主移动的精细控制带来不利因素。所以很早就想把它改成舵机控制的了，下面就是整个改造的过程。

这就是需要改造的部分。

先将需要改造的部分画下来，便于设计框架结构。我不是机械出身的，所以就画个大概吧。

结构图完成

在图纸上设计新的结构

根据设计切割材料

最后完成的样子，由于是临时电路，也就没固定，看上去有点像垃圾车-_-b

改造部分的特写

再来一张

这些只是机械部份，然后就是控制部份。由于舵机能够转动的角度范围到180度，而该车的转向轮仅能转动在30-40度之间。同时，自主移动机器人目标是在Arduino上面开发。所以我就一步到位，先用Arduino读取天地飞的pwm信号，然后经过转换，输出新的pwm信号给舵机，这样就不会因为卡住而损坏舵机了。

最后效果如下

http://v.youku.com/v_show/id_XMjYzOTc2NzA4.html

使用的程序非常简单，如下：

#include <Servo.h>
//Author:	HE Qichen
//Date:	2011-5-3
//Website:	http://gaishi.vicp.net
//Email:	heqichen(a)gaishi.vicp.net
Servo directionServo;
void setup()
{
  pinMode(2, INPUT);
  directionServo.attach(3);
}
void loop()
{
  int t, a;
  t = pulseIn(2, HIGH);
  a = map(t, 1000, 2000, 65, 115);
  directionServo.write(a);
}

]]>

嵌入之梦-圆梦小车开发 May 1st, 2011

今天看到一台嵌入之梦的小车，但是上电之后发了疯似的乱跑，所以刷之。但新车间却没有网络，没办法，自己一点一点试。。结果如下

CT1	接受pwm，控制速度
CT2	前进控制信号，高电位转动
CT3	后退控制信号，高电位转动

但是由于小车上的UNO与我的Ubuntu连接有问题，貌似只有Windows是好的，Mac OS有时也会出问题。所以最后车上改用了Mega 1280。

但是又发现一个问题，就是Arduino使用USB供电的时候很正常，然而，使用车上接出来的5V电源时，程序就会混乱，完全没有一点规律。猜测可能是由于电机转动导致整个系统的电压下降，无法提供足够的电压给Arduino的板子上。这大概也是之前uno不会发疯的原因。没办法，在小车上再接一块9V层叠式电池，作为Arduino的电源。最后终于行了。

后面程序的作用是往前走，遇到前方有物体是后退，打弯，然后继续往前，一个简单的壁障程序。没有用到速度控制。下面就是这个小车最后的样子，手机拍的，将就看吧

左侧照

右侧照

再来一张

http://v.youku.com/v_show/id_XMjYzMzY0NzA0.html

用到的程序就是下面的

//Author:	HE Qichen
//Email:	heqichen(a)gaishi.vicp.net
//Website:	http://gaishi.vicp.net
//Date:	2011-5-1
int status;
#define LEFT_SPEED   6
#define LEFT_FORWARD  7
#define LEFT_BACKWARD  8
#define RIGHT_SPEED  10
#define RIGHT_FORWARD  11
#define RIGHT_BACKWARD  12
#define ULTRASONIC_ECHO  3
#define ULTRASONIC_TRIG  4
#define NORMAL_SPEED  100
#define STOP_SPEED  0
void setup()
{
  Serial.begin(9600);
  setupMove();
  setupUltrasonic();
}
void loop()
{
  unsigned int d;
  moveForward();
  d = readDistance();
  Serial.println(d, DEC);
  if (d < 700)
  {
    moveBackward();
    delay(500);
    turnLeft();
    delay(200);
  }
}
void moveForward()
{
  analogWrite(LEFT_SPEED, NORMAL_SPEED);
  digitalWrite(LEFT_BACKWARD, LOW);
  digitalWrite(LEFT_FORWARD, HIGH);
  analogWrite(RIGHT_SPEED, NORMAL_SPEED);
  digitalWrite(RIGHT_BACKWARD, LOW);
  digitalWrite(RIGHT_FORWARD, HIGH);
}
void moveBackward()
{
  analogWrite(LEFT_SPEED, NORMAL_SPEED);
  digitalWrite(LEFT_BACKWARD, HIGH);
  digitalWrite(LEFT_FORWARD, LOW);
  analogWrite(RIGHT_SPEED, NORMAL_SPEED);
  digitalWrite(RIGHT_BACKWARD, HIGH);
  digitalWrite(RIGHT_FORWARD, LOW);
}
void turnLeft()
{
  analogWrite(LEFT_SPEED, NORMAL_SPEED);
  digitalWrite(LEFT_BACKWARD, HIGH);
  digitalWrite(LEFT_FORWARD, LOW);
  analogWrite(RIGHT_SPEED, NORMAL_SPEED);
  digitalWrite(RIGHT_BACKWARD, LOW);
  digitalWrite(RIGHT_FORWARD, HIGH);
}
void turnRight()
{
  analogWrite(LEFT_SPEED, NORMAL_SPEED);
  digitalWrite(LEFT_BACKWARD, LOW);
  digitalWrite(LEFT_FORWARD, HIGH);
  analogWrite(RIGHT_SPEED, NORMAL_SPEED);
  digitalWrite(RIGHT_BACKWARD, HIGH);
  digitalWrite(RIGHT_FORWARD, LOW);
}
void moveStop()
{
  analogWrite(LEFT_SPEED, STOP_SPEED);
  digitalWrite(LEFT_BACKWARD, LOW);
  digitalWrite(LEFT_FORWARD, LOW);
  analogWrite(RIGHT_SPEED, STOP_SPEED);
  digitalWrite(RIGHT_BACKWARD, LOW);
  digitalWrite(RIGHT_FORWARD, LOW);
}
void setupMove()
{
  pinMode(LEFT_SPEED, OUTPUT);
  pinMode(LEFT_FORWARD, OUTPUT);
  pinMode(LEFT_BACKWARD, OUTPUT);
  pinMode(RIGHT_SPEED, OUTPUT);
  pinMode(RIGHT_FORWARD, OUTPUT);
  pinMode(RIGHT_BACKWARD, OUTPUT);
  analogWrite(LEFT_SPEED, STOP_SPEED);
  digitalWrite(LEFT_FORWARD, LOW);
  digitalWrite(LEFT_BACKWARD, LOW);
  analogWrite(RIGHT_SPEED, STOP_SPEED);
  digitalWrite(RIGHT_FORWARD, LOW);
  digitalWrite(RIGHT_BACKWARD, LOW);
}
unsigned int readDistance()
{
  int duration;
  digitalWrite(ULTRASONIC_TRIG, LOW);
  delayMicroseconds(2);
  digitalWrite(ULTRASONIC_TRIG, HIGH);
  delayMicroseconds(5);
  digitalWrite(ULTRASONIC_TRIG, LOW);
  // The same pin is used to read the signal from the PING))): a HIGH
  // pulse whose duration is the time (in microseconds) from the sending
  // of the ping to the reception of its echo off of an object.
  duration = pulseIn(ULTRASONIC_ECHO, HIGH);
  return duration;
}
void  setupUltrasonic()
{
  pinMode(ULTRASONIC_TRIG, OUTPUT);
  pinMode(ULTRASONIC_ECHO, INPUT);
  digitalWrite(ULTRASONIC_TRIG, LOW);
}

]]>

自主机器人项目

我想通过改造一辆遥控小车，造出个自主移动机器人，遥控车就是下面这张图片中的车。

并且希望通过大家的智慧，把这个机器人做好，比如说，想在上面放一个无线摄像头；比如说，在上面放一个机械手臂；比如说，在这上面装一个超声测距模块……我将集中大家的智慧，集合到这个小车上面，^_^

http://v.youku.com/v_show/id_XMjYyMzQ4OTYw.html

如果你有想法，请告诉我 hacker(a)gaishi.vicp.net

]]>
